WIDOS Miniplast 2 (OD 20 to OD 110 mm)

WIDOS Miniplast 2 (OD 20 to OD 110 mm)

Butt-welding machine with heating element for the workshop, building site and installation.

The Miniplast/2 is a welding machine for the heating element butt welding of PE, PP and PVDF pipes and fittings from OD 20 to OD 110 mm.

The WI-PRECISION® basic machine has two large aluminium basic clamping tools which are swivelling 15° on each side for the fabrication of segmented bends. By screwing in 4 small reduction clamping inserts, a double clamping is obtained at smaller diameters. For fittings with short legs, a small fitting clamping tool is available. Due to the special construction of the pressure build-up device, the machine can be fixed directly at very short pipe ends on walls and sheets.

Due to its light and compact construction, the machine is ideally suited for the use in pipeline system and for assembly work. In case of stationary use, the machine can be fixed in the vice or with the table support. In addition, an extended version for the fabrication of T-pieces and elbows 90° (up to OD 90 mm) is available. On both sides, each basic clamping tool can be swivelled up to 45°. This basic machine is vertically and horizontally adjustable

WI-CUTTING®. The light and compact manual   planer is operated by means of a ratchet.

WI-HEAT® heating element in accordance with DVS 2208 (230 V/500 W) has a diameter of ≈120mm, an anti-stick coating and control lamps for system and interval checking. For the safe storage of the planer and heating element, a heat-protected box is available. The sheet steel carrying case serves for the transport and protected storage of the complete Miniplast/2.
