PIPES CABLE PROTECTION PIPES
Rigid Conduit PIPE 750 N
| Dimension | ID Tolerance | OD Tolerance | Coils Length ( M ) |
|---|---|---|---|
| 40 | 35.10 + 0.20 | 40.00 + 1.20 | 6 |
| 50 | 41.00 + 0.20 | 50.00 +1.20 | 6 |
| 63 | 51.00 + 0.20 | 63.00 + 1.20 | 6 |
| 75 | 62.00 + 0.20 | 75.00 + 1.20 | 6 |
| 90 | 75.00 + 0.25 | 90.00 + 2.00 | 6 |
| 110 | 94.00 + 0.25 | 110.00 + 2.00 | 6 |
| 125 | 108.00 + 0.3 | 125.00 +3.00 | 6 |
| 160 | 138.00 + 0.3 | 160.00 + 3.00 | 6 |
Product dimensions are according to EN 61386-24.
Compression test > 750 N vertical deflection equivalent 5% of the original diameter.
Any other lengths are available upon request.
Spacer:
Coupling: Coupling provides sandtight joints. Profile sealing will provide watertight seals
